129
General View of the Balances
LA310S (-0CE), LA230S (-0CE), LA230P (-0CE), LA120S (-0CE)
-0CE identifies the precision balances as verified for legal metrology in the EU*
Pos. Designation Order No.
for replacement
1 Weighing pan 69 LA0006
2 Shield disk 69 A20003
3 Shield plate 69 LA0008
4 Bushing (pan adapter) 69 LA0007
5 Leveling foot 69 B20005
6 Display and control unit
7 Metrological ID label
(only on balances verified for legal metrology)
8 Lug for attaching an anti-theft
locking device
9 DC jack
10 Tare key
Pos. Designation Order No.
for replacement
11 Function keys
12 Print key
13 Numeric keys
14 On/off key
15 Toggle key for alphabetic input
16 Display
17 Data interface port
18 Level indicator
Not shown:
In-use dust cover 6960LA01
Protective caps and plugs (set) 69 B20009
