24 MICRA SATEL
module status are not included in the number of transmissions and are not limited. You
can enter any value from 0 to 255. Entering 0 means no transmission limit (default: 0).
Monitoring station 1 / Monitoring station 2
Notes:
• Using GPRS technology, event codes can be sent to the STAM-2 monitoring station or to
the SMET-256 converter.
• Communication with the subscriber sending event codes with the use of GPRS
technology should be tested by the monitoring station as rarely as possible (if a value
lower than 1 minute is entered in the “Test period” field of the monitoring station, the time
will be rounded up by the module to 1 minute). It is recommended that the maximum
value be set, i.e. 255 seconds.
Disabled – if this option is selected, event codes will not be sent to the monitoring station.
SMS – if this option is selected, event codes will be sent to the monitoring station in the form
of SMS messages.
GPRS – if this option is selected, event codes will be sent to the monitoring station with the
use of GPRS technology.
GPRS, SMS if GPRS failure – if this option is selected, event codes will be sent to the
monitoring station with the use of GPRS technology, but after a failed attempt of sending
events (lack of receipt acknowledgement from the monitoring station), the event code will
be sent in the form of SMS message.
Tel. number (SMS) – GSM telephone number used by the monitoring station for receiving
SMS messages. Must be preceded by the country code.
Address (GPRS) – address of the monitoring station. It can be entered in the IP address
form (4 decimal numbers separated by dots) or as a name.
Port (simple mode) – number of TCP port through which communication with the monitoring
station will be effected. The port number must be the same as that programmed in the
monitoring station for managing subscribers in the simple mode.
Station key – enter in this field a string of 1 to 12 alphanumeric characters (digits, letters and
special characters) which define the encryption key for the data to be sent to the
monitoring station. It must be consistent with that defined in the monitoring station
for managing subscribers in the simple mode.
GPRS key – a string of 1 do 5 alphanumeric characters identifying the module. It must be
consistent with that defined in the monitoring station ("ETHM/GPRS key").
Advanced encryption – enabling this option will increase the security level of data
transmitted to the monitoring station. This option requires a SMET-256 converter with
firmware version 1.06 or higher, or STAM-1 PE and STAM-1 RE cards, version 3.03 or
higher.
Port (extended mode) – number of TCP port at which communication with the monitoring
station will be checked. The port number must be the same as that programmed in the
monitoring station for managing subscribers in the extended mode.
Object identifier – enter in this field 4 characters (digits or letters from A to F) which will
serve as an identifier during the test transmissions sent by the module. Do not enter
value 0000 (the module will not be sending test transmissions to the monitoring
station). Using digit 0 in the identifier is not recommended.
SMS format
The format of SMS messages for SMS reporting must be defined according to the monitoring
station requirements. The default SMS messages format programmed in the module
corresponds to the factory default settings of the STAM-2 monitoring station (program version
