– FT – FT output (colors have the same meaning as for the relay outputs);;
– MKP-300 – wireless keypad:
green – keypad registered;
red – keypad tamper;
gray – keypad not registered.
Under the field corresponding to the wireless keypad, a bar is displayed to
illustrate the level of communication between keypad and module. The bar color
provides the following information:
– red – no transmission from the keypad for 30 minutes.
– green – quality of communication between keypad and module. The bar length
illustrates how many packets were received during the last transmission.
– module operating in alarm device mode (e.g. about armed mode, exit delay, entry
delay, alarm).
Buttons:
Read from file – button enables loading configuration data from file.
Write to file – button enables saving configuration data to file.
Read – button enables reading data from the module.
Write – button enables saving data to the module.
Abort – button enables terminating the data reading/writing.
Set RTC – button enables writing computer time to the module.
Start test transmission – button starts sending the test transmission (in case
of remote programming, the test transmission will only be sent after
completion of the communication with the module).
Configuration – button enables opening the "Connection" window. The window
enables configuration of parameters relating to the mode of communication
between program and module:
– select the computer COM port through which local programming is to be
effected;
– enter the number of TCP port to be used for remote programming of the
module. Values from 1 to 65535 can be entered.
4.3.2 „OPTIONS, ZONES, OUTPUTS” TAB
Operation mode
Selection of the operating mode will change the module functionality.
Select the mode in which the module is to work:
Communication device – the main task of the device is to provide information about the
state of equipment connected to the module, as well as of the module itself, by means of
reporting or messaging.
Alarm device – the main task of the device is to be protection of the premises and signaling
a burglary, if any (default setting).
