32 MICRA SATEL
– XYZ – 3-digit event code.
Code entering is facilitated by the Contact ID code editor, which you can start by
clicking the button, available in the "EVENT" field.
Part. – partition number which will be sent in the event code. You can enter numbers and
letters from A to F.
Note: If events are to be sent in the form of two characters (partition number only), you
should not use the code editor.
Z. No. – zone / module / user number which will be sent in the event code.
EVENT – event description corresponding to the Contact ID code entered in the "CODE"
field. Available in the "EVENT" field is also the button, which enables opening of the
code editor.
4.3.7 „KEYFOBS” TAB
Keyfobs
Serial no. – w polu wyświetlany jest numer seryjny pilota.
User name – you can enter in this field the name of user to whom the keyfob is assigned.
The name can have up to 16 characters. After entering the name, a digit (1 – 8),
corresponding to the code number in the MKP-300 keypad, will appear automatically next
to the name.
Buttons – you can assign one of the functions below to each of the keyfob buttons and to the
1 & 2 / plus 1 & 3 / combinations of buttons (you can make your selection in the
right-click drop-down menu, or by entering a digit corresponding to the selected function):
0: no function
1: out 1 ON
2: out 2 ON
3: out 1 ON (time)
4: out 2 ON (time)
5: out 1 OFF
6: out 2 OFF
7: bypass zones [communications device] / 7: disarming [alarm device]
8: unbypass zones [communications device] / 8: arming [alarm device]
9: clear alarm [alarm device]
10: panic alarm [alarm device]
Notes:
• The button numbers and their combinations refer to the P-2, P-4, T-1, T-2, T-4 keyfobs,
while the icons and their combinations refer to the MPT-300 keyfob.
• Even if pressing a button starts no function in the module ("0: no function" is selected), it
may result in sending an event code which has been assigned to that button below, in the
"Reporting" tab. Thus you can trigger e.g. the silent panic alarm – the event code will be
sent to the monitoring station, but the alarm will be in no way signaled by the module.
New keyfob – the button allows you to add a keyfob (if a keyfob has already been added in
the given position, it will be replaced with a new one, but the name and functions assigned
to the keyfob buttons will be retained).
Remove keyfob – the button allows you to remove a keyfob (the name and functions
assigned to keyfob buttons will also be deleted).
