Section 3: Loading Paper
CG2 Series Quick Guide Page 3-5
4. Close the top cover. Press the top cover down from above in the direction of the arrows until it clicks into
position.
5. When the printer is offline, the ON LINE (POWER) lamp blinks. Press the FEED/LINE button (1). The
printer is online and the ON LINE (POWER) lamp is on. When the printer is ready, press the FEED/LINE
button to output the top part of the paper.
CAUTION
• After printing, the print head and surrounding area are hot. Be careful not to get burned when replacing
paper immediately after printing.
• Touching the edge of the print head with bare hands could result in an injury.
• The cutter is sharp. Be careful not to cut your hands.
• Be careful not to get your fingers pinched while closing the top cover.
ON LINE (POWER) lamp
①
ON LINE (POWER) lamp
①
