Section 3: Loading Paper
Page 3-6 CG2 Series Quick Guide
LOADING ROLL PAPER (DISPENSER TYPE)
1. Pull toward you the cover open and close latches on the both sides of the printer in order to unlock the top
cover. Then, open the top cover (1).
2. Open the dispenser unit.
3. Remove the lead label, leaving only the backing paper. Load the paper in the paper holder. After pulling out
the paper, pass the paper through the paper sensor. Pass the paper over the dispenser bar so as to cover
it.
Dispenser bar
Dispenser unit
Dispenser bar
Dispenser unit
To Next Page
