Section 3: Loading Paper
CG2 Series Quick Guide Page 3-7
4. Load the backing paper so that it sticks out from the bottom of the dispenser unit. If the paper is not taut,
roll the paper on the paper holder so that the paper is taut. Next, tightly close the dispenser unit by press-
ing it in the direction of the arrow.
5. Close the top cover. Press the top cover from above in the direction of the arrows until it clicks into posi-
tion.
6. When the printer is offline, the ON LINE (POWER) lamp blinks. Press the FEED/LINE button (1). The
printer is online and the ON LINE (POWER) lamp is on. When the printer is ready, press the FEED/LINE
button to output the top part of the paper.
Output label
Output backing paper
Output label
Output backing paper
ON LINE (POWER) lamp
①
ON LINE (POWER) lamp
①
To Next Page
