Section 4: Cut Position Adjustment
CG2 Series Quick Guide Page 4-3
3. The cutter unit has a valid cut pitch of 0.98 to 23.74 inches (25 to 603 mm) (203 dpi)/0.98 to 15.87 inches
(25 to 403 mm) (305 dpi).
4. The perforated line +0.04 inch (1 mm) is the cut prohibited zone (Fig. 1).
5. The folded perforated line 0.16 to 0.98 inch (+4 to +25 mm) of fan-folded paper is the cut prohibited zone
(Fig. 2).
6. After adjusting the stop position, dispense two to five labels to fix the cut position.
)2 .giF()1 .giF(
Cut prohibited
zone
Perforated line
Fold perforation
25 mm
4 mm
To Next Page
