Unit 4: Standard Command Codes
SATO GL4xxe SBPL Programming Reference Page 4-38
OUTPUT
Without incrementing:
(4-26a)
With incrementing:
(4-26b)
NOTES
UCC128 code is exclusive to Standard Carton ID. When printing in EAN128,
designed for the markets in the medical, fresh food, or flowers and plants, use
CODE128 Barcode <ESC>BG to specify print data with application identification or
separator that matches each specification.
Start character code, function character, end character code, and identification code
(corresponds only to “00”) are added automatically.
Modulus 10 check character and modulus 103 check character are automatically
generated.
Sequential number of barcode data is available.
Line pitch between barcode and expository font is fixed at 10 dots.
If the width of expository font is wider than that of the barcode, it starts printing from
the print start position of barcode.
If the width of expository font is narrower than that of the barcode, expository font will
be aligned to the center of barcode for printing.
Prints expository font in OCR-B.
If the expository font is outside of the print area, it will not be printed. When HRI is
available, specify Vertical Print Position (<ESC>V) and Horizontal Print Position
(<ESC>H) in consideration of print of expository font.
SSCC
