SATO GL4xxe Series User Manual

Unit 4: Printer Configuration
GL408-412e Operator’s Manual
4-3
CONFIGURATION MODES
This chapter provides an overview of the various configuration modes of the operation menu. All of the
configuration activities are performed via the use of the operator panel located on the printer’s face. However,
many settings may also be controlled via external software commands.
USER MODE
This mode allows configuration of printing features that are prone to change from job to job. These are some of the
most basic and common adjustments of all of the configuration modes.
Refer to the Menu Definition Tables in the following chapter to provide an explanation of each menu screen.
Figure 4-1, User Mode
USER MODE
POWER
ONLINE
OFFLINE
LINE
FUNCTION
ENTER
Print Speed
4 ips*
Print Darkness
5*
Pitch Offset
00.0 mm*
Ver Print Offset
00.0 mm*
Hor Print Offset
00.0 mm*
Label Length
152 mm*
Label Width
104 mm*
Slash Zero
Disable*
Character Pitch
Proportional*
Protocol C. Code
Standard*
Euro Character
213*
Ver BaseRefPoint
0 dots*
Hor BaseRefPoint
0 dots*
Mem Select (CC1)
Card*
Orientation
Portrait*
Units
In Millimeters*
USER MODE
Print Speed
Print Darkness
Pitch Offset
Ver Print Offset
Hor Print Offset
Label Length
Label Width
Slash Zero
Character Pitch
Protocol C. Code
Euro Character
Ver BaseRefPoint
Hor BaseRefPoint
UPC Descenders
Vert. DPI Adjust
C128 Mode Switch
Error Handling
Mem Select (CC1)
Orientation
Slew Speed Ctrl
Print Direction
Tear-Off Time
Label Missing
Clip Page
Fault Reprint
Display Ribbon
Ribbon Near End
Units
Set Label Length
TOF Detect Fault
TOF Adjust Mode
TOF Adjust
UPC Descenders
Always*
Vert. DPI Adjust
0*
C128 Mode Switch
Manual*
Error Handling
Beep*
Slew Speed Ctrl
Automatic*
Print Direction
Head First*
Tear-Off Time
01.0 seconds*
Label Missing
Fault Disable*
Clip Page
Enable*
Fault Reprint
Enable*
Display Ribbon
Enable*
Ribbon Near End
Enable*
Set Label Length
Manual*
TOF Detect Fault
3 labels*
TOF Adjust Mode
Disable*
TOF Adjust
10.1 mm*
Screens
only display if
Admin User is
enabled within the
Advanced
Mode

SATO GL4xxe Series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max. Print Width	104 mm (4.09 inches)
Media Type	Roll, Fanfold, Tag, Ticket
Media Width	25.4 mm - 118 mm (1 inch - 4.65 inches)
Media Thickness	0.06 mm - 0.25 mm (0.0024 inch - 0.0098 inch)
Interfaces	USB, Serial, Ethernet, Parallel
Barcodes	1D and 2D barcodes
Scanning Technology	N/A (Printer, not a scanner)
Scan Rate	N/A (Printer, not a scanner)
Resolution	N/A (Printer, not a scanner)
Interface	N/A (Printer, not a scanner)
Operating Temperature	5°C - 40°C (41°F - 104°F)
Storage Temperature	14°F to 140°F (-10°C to 60°C)
Humidity	20% - 85% (non-condensing)
Lighting	N/A (Printer, not a scanner)
Power Supply	AC 100-240 VAC ±10%, 50/60 Hz
