Unit 2: Technical Data
GL408-412e Operator’s Manual
2-3
SENSING
Gap Position & Sensitivity Adjustable
Reflective Eye-Mark Position & Sensitivity Adjustable
Ribbon Near End Fixed (enabled/disabled)
Media Out Fixed (always enabled)
Ribbon Out Fixed (always enabled)
Cover Open Fixed (always enabled)
MEDIA
Width
Media Width: 0.87 to 5.04 Inches (22 - 128mm)
Media Width with Backing Paper: 0.98 to 5.16 Inches (25 - 131mm)
Length (Continous)
Media Length: 0.24 to 15.63 Inches (6 - 397mm)
Media Length with Backing Paper: 0.35 to 15.75 Inches (9 - 400mm)
Length (Tear-Off)
Media Length: 0.67 to 15.63 Inches (17 - 397mm)
Media Length with Backing Paper: 0.79 to 15.75 Inches (20 - 400mm)
Type
Roll or Fan-Fold
Eye-Mark or Gap
Direct Thermal or Thermal Transfer
Thickness 0.002 to 0.010 Inches ( 0.06 - 0.268 mm)
Roll Diameter Maximum: 10.43 Inches (265mm)
Core Diameter 1.5 to 4.0 Inches (38.1 - 101.6mm)
Wind Direction Face In, Face Out (linerless only)
Fan-Fold Height Maximum: 7.87 Inches (200mm)
RIBBON
Width Maximum: 5.04 Inches (128mm)
Length 1476 Feet (450M)
Wound Face In, Face Out
Core Diameter 1.00 Inch (25.6 mm)
Roll Diameter Maximum: 3.35 Inches (85 mm)
REGULATORY
Radiation Noise
FCC Part 15, Subpart B, Class B
EN55022 Class B
Static Electricity IEC61000-4-2, Level 3
AC Line Noise Above: 1000Vp-p
Packing Drop Standard ISTA-2A
Environmental (RoHS)
Chromium: below 0.1%
Lead: below 0.1%
Mercury: below 0.1%
Cadmium: below 0.01%
Polybrominated Bipheny (PBB): below 0.1%
Polybrominated Diphenyl Ether (PBDE): below 0.1%
