8 Appendix
344
S84-ex/S86-ex Operator Manual
Timing chart of error signal output with one-shot pulse
Item
RFID reprint twice - One-shot Pulse Output Waveform
PV
End of error print
(PREND)
Print End
Print
Reprint 1stReprint 2nd Error
Paper End/
Ribbon End
RFID tag error
Machine Error
TYPE 1
TYPE 2
TYPE 3
TYPE 4
RFID write error
100 - 500 ms
PV
End of error print
(PREND)
Print End
Print
Paper End/
Ribbon End
RFID tag error
Machine Error
TYPE 1
TYPE 2
TYPE 3
TYPE 4
RFID write error
100 - 500 ms
PV
End of error print
(PREND)
Print End
Print
Paper End/
Ribbon End
RFID tag error
Machine Error
TYPE 1
TYPE 2
TYPE 3
TYPE 4
RFID write error
100 - 500 ms
