8.12.2 Ribbon and Media
Ribbon (Use genuine ribbon made by SATO.)
Size S84-ex Width: 25 mm to 128 mm (0.98” to 5.04”)
Length:
450 m (1476.4 ft.) when width is less than 39.5 mm (1.55”)
600 m (1968.5 ft.) when width is equal or more than
39.5 mm (1.55”)
S86-ex Width: 59 mm to 177 mm (2.32” to 6.97”)
Length: 600 m (1968.5 ft.) when width is equal or more than
59
mm (2.32”)
Wind Direction Face-out/Face-in
Roll Diameter 108 mm (4.25”)
Core Diameter 25.6 mm (1.01”)
Media (Use genuine media made by SATO.)
Type Media roll (Face-in wound/face-out wound), fan-fold media
Size
Continuous Mode
Pitch
(With Liner)
* There is a restriction
with the speed for the
small pitch label.
S84-ex 203 dpi: 6 to 2500 mm (0.24” to 98.42”)
305 dpi: 6 to 1500 mm (0.24” to 59.06”)
609 dpi: 6 to 400 mm (0.24” to 15.75”)
S86-ex 203 dpi: 6 to 1249 mm (0.24” to 49.17”)
305 dpi: 6 to 1249 mm (0.24” to 49.17”)
S84-ex 203 dpi: 9 to 2503 mm (0.35” to 98.54”)
305 dpi: 9 to 1503 mm (0.35” to 59.17”)
609 dpi: 9 to 403 mm (0.35” to 15.87”)
S86-ex 203 dpi: 9 to 1252 mm (0.35” to 49.29”)
305 dpi: 9 to 1252 mm (0.35” to 49.29”)
Width
(With Liner)
S84-ex 10 to 128 mm (0.39” to 5.04”)
S86-ex 51 to 177 mm (2.01” to 6.97”)
S84-ex 13 to 131 mm (0.51” to 5.16”)
S86-ex 54 to 180 mm (2.13” to 7.09”)
