Tightening torque for screw joint
OPM 100 en-GB 118
© Scania CV AB 2023, Sweden
Tightening torque for screw
joint
Screws and nuts
Hexagon screws, hexagon socket
screws, Torx screws, hexagon nuts
Metric thread. Strength class 8.8/8.
Flange screws with hexagonal head
and hexagonal flange nuts
Metric thread. Strength class 8.8/8.
Thread
Tightening torque
Nm Lb-ft
M4 2.9 21
M5 6 4
M6 9.5 7
M8 24 18
M10 47 35
M12 84 62
M14 135 100
M16 210 155
M18 290 214
M20 420 310
M22 580 428
M24 730 538
Thread
Tightening torque
Nm Lb-ft
M5 6.7 5
M6 10.2 8
M8 26 19
M10 50 37
M12 92 38
M14 149 110
M16 184 136
