Scania DC09 - Renewing Downwards-Moving Centrifugal Oil Cleaner Rotor

OPM 100 en-GB 62
© Scania CV AB 2023, Sweden
Lubrication system
9.
Remove the bottom cover together with the
rotor.
10. Remove the rotor by pulling it straight up
from the cover. See illustration.
IMPORTANT!
Lubricate the threads on the cover and O-rings
with engine oil before they are refitted.
11. Renew the uppermost black O-ring.
12. Renew the 2 lower green O-rings.
