Cooling system
Cleaning the heat exchanger
1. Remove the cover and pull out the cooler
core.
2. Clean the outside of the cooler core.
IMPORTANT!
Use a paraffin-based engine cleaning agent.
3. Remove any internal deposits using a round
rod.
4. Replace damaged and hard O-rings.
5. Assemble the heat exchanger.
6. Tighten the screws to 15-18 Nm.
7. Fit the heat exchanger according to the de-
scription.
1. Screw
2. Rear cover
3. O-ring
4. Cooler core
5. Housing
6. Flange
7. Front cover
1
1
6
7
2
3
4
5
3
3
3
325 160
