DANGER!
Risk of electrocution!
Risk of electrocution!
Please adhere to the following points:
• The phase must be fused at the ampere value specified on the serial plate.
• It must be possible to disconnect the device from the mains power supply at all poles.
• The electrical system at the installation site must conform to IEC 364 (DIN VDE 0100). To
increase safety, the device should be connected to a ground fault circuit interrupter with 30
mA nominal error current (EN 61008). (Type B residual current circuit breakers ensure re-
sponse even in the event of smooth DC residual currents. This results in a high level of
safety.)
• Never operate a device with a damaged power cable. Have a defective power cable or plug
replaced immediately by a qualified service technician.
• Schaerer AG does not recommend using an extension cord. If an extension cord is used
despite this (minimum cross-section: 1.5 mm²), please comply with the manufacturer’s
specifications for the cable (operating instructions) and with locally applicable regulations.
• Route the power cable in such a way that it does not pose a tripping hazard. Do not pull
the cable over corners or sharp edges, pinch it between objects or allow it to hang loosely
in open spaces. Do not position the cable over hot objects, and protect the cable from ex-
posure to oil and aggressive cleaning products.
• Never lift or pull the device by the power cable. Never pull the plug out of the socket by its
cable. Never touch the power cable or plug with wet hands. Never insert a wet plug into a
power socket.
Connection values
Mains
Fuse pro-
tection
(building
side)
Connecting
cable, con-
ductor cross-
section
1L, N, PE 220 – 240 V~ 50/60 Hz 2000 – 2400 W 10 A 3 x 1 mm²
3000 – 3600 W 16 A 3 x 1.5 mm²
5700 – 6900 W 30 A 3 x 4 mm²
2L, PE 200 – 220 V 2~ 50/60 Hz 2000 – 2200 W 2 x 15 A 3 x 1.5 mm²
2600 – 3200 W 2 x 15 A 3 x 1.5 mm²
4700 – 5900 W 2 x 25 A 3 x 10 AWG
4700 – 5900 W 2 x 30 A 3 x 10 AWG
3L, N, PE 380 – 415 V 3N~ 50/60 Hz 5700 – 9200 W 3 x 16 A 5 x 1.5 mm²
8300 – 10100 W 3 x 16 A 5 x 1.5 mm²
3L, PE 200 V 3~ 50/60 Hz 7000 W 3 x 20 A 4 x 2.5 mm²
4700 – 5800 W 3 x 30 A 4 x 10 AWG
3L, PE 220 V 3~ 50/60 Hz 6900 – 8500 W 3 x 25 A 4 x 2.5 mm²
