Appendix
User manual SI 2 - EN 83
Version 02 / 06.2005 / REWE www.schaerer.com
Serial plate
Machine-specific data (voltage / output) can be found on the serial plate.
It is affixed to the back of the device under the cable cover.
Maximum voltage deviation: + 5% / - 10%
Technical data
Dimensions ( W x H x D ):
Standard model: 314 x 508 x 403 mm
With coin tester option: 415 x 415 x 403 mm
With wastewater option: 314 x 508 x 460 mm
Water tank (capacity): 2.4 litres
Cord: 1.1 m
Weight (standard model): 15.7 kg
Safety tests: International test marks
Electrical socket:
Do not use any multiple sockets, especially if devices such as air
conditioners, computers, typewriters or copiers are connected to it and
can generate interfering frequencies.
Do not overload the electrical socket!
The connected consumers must not exceed the amperage of the house
fuse.
