Scheppach Capas 5

english 13
Manufacturer:
scheppach
Manufacture of Woodworking Machines GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Valued customer,
Wehopethatyouenjoyyournewmachineandwishyou
every success in working with it.
Warning:
The manufacturer of these devices is not liable, under the
applicableProductLiabilityAct,fordamagestothisdevice
or by this device resulting from:
• improperhandling,
• noncompliancewiththeoperatinginstructions,
• repairsbyathird,nonauthorizedparty
• installation and replacement of nonoriginal spare
parts,
• utilization,noncompliantwiththeregulations,
• failureoftheelectricequipmentresultingfromviolation
of the electric specications and VDE (Association of
Electrotechnology)regulations0100,DIN57113/VDE
0113.
We advise you:
Beforeassemblyandimplementation,pleasereadtheop-
erating instructions in their entirety.
Theseoperatinginstructionsshouldmakeiteasierforyou
togetacquaintedwithyourmachineandtouseitasin-
tended.
The operating instructions contain important indications
thatwillhelpyouworkprofessionallyandefcientlywith
the machine, at the same time avoiding risks, saving on re-
paircosts,decreasingdowntimeandincreasingreliability
andlifespanofthemachine.
Inadditiontothesafetyregulationsprovidedintheoperat-
inginstructions,youmustobservetheapplicableregula-
tions of your country for the use of this machine.
Youshouldkeeptheoperatinginstructionsnearthema-
chine.Theyareprotectedfromdirtandmoisturebyaplas-
tic covering. These must be read and followed diligently
byanyoperator,beforestaringthework.Onlythose,who
have been instructed on the use and informed of all the
associated risks, should work on the machine. Minimum
agerequirementsshouldbeobserved.
General Considerations
• After unpacking,pleasecheck all oftheparts for any
possibledamagesintransit.Thefeedermustbeimme-
diatelynotiedofanycomplaints.Lateclaimswillnot
beaccepted.
• Checkthattheshipmentiscomplete.
• Before use, familiarize yourself with the operating in-
structions.
• Pleaseuseonlyoriginalpartsassupplies,suchaswear
andtearandreplacementparts.Youcanobtainreplace-
mentpartsfromyourspecializeddealer.
• Whenordering,pleasegiveouritemnumber,aswellas
thetypeandtheyearofmanufactureofthedevice.
Capas 5
Complete Delivery Contains:
CrownedsawCapas5
Bevellatchgrip
Fastening vice
Dust bag
Saw blade key
Smallparts
Operatinginstructions
Technical Data
Dimensions L x B x
H mm
860x650x700
Mounting table ø mm
328
Saw blade ø mm
255/30WZZ40
Speed of Rotation/
min.
4000
Bevel angle
0°–45°left
0°–60° right
Screen position °
0/15/22,5/31,6/45/60right
0/15/22,5/31,6/45left
Possible angle of
inclination
°0–45rightandleft
Weight kg
24.3
Cutting data
90°/0°
305 x 80 mm
90°/45°
204x80mm
45°/0°
305x42mm
45°/45°
204x42mm
Power
Motor Va.c./Hz
230/50
Intake Capacity P1 W
1800
Production Capacity
P2 W
1050
Subject to technical changes!
Information on the subject of noise development
Thelevelofnoiseproducedbythismachineduringitsop-
eration is as follows:
Maximumnoisepressurelevel:95.9dB(A)
Maximumnoiseperformancelevel:108.9dB(A)
Maximumvibrationlevel:1.52m/s
2
Warning: Noise can have adverse health effects. Should
thenoiselevelincreaseabove85dB(A),youmustwear
earprotection.Should the electrical supply not be opti-
mal,thenthecurrentcandropforashorttimewhenthe
machineisturnedon.Thiscaninuenceotherequipment
(forexample,theblinkingofalamp).Shouldtheelectrical
capacityhaveaZmax<0.27,suchdisturbancesarenotto
beexpected.(Shouldyouhavedifculties,pleaseconsult
yourlocaldealer.)
In these operating instructions we have noted those passages
which refer to your safety with this sign: m
m General Safety Issues
WARNING! When working with electrical tools, certain basic
safetyproceduresmustbeobservedinordertokeepthe
