Scheppach HS100S Operating Manual

 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
15. Troubleshooting
Problem Possible Cause Help
Saw blade gets loose
after turning off the
motor
Fastening nut tightened insufciently Tighten fastening nut, M20 left-handed thread
Motor does not start a) Fastening nut tightened insufciently
b) Extension cable defect
c) Connections on the motor or switch defect
a) Check the mains fuse.
b) See “Electrical Connection” in the operating
manual
c) Have it checked by an electrician
No motor output turns
off automatically
Overload by dull saw blade, thermoprotection
is triggered
Insert a sharpened saw blade; motor can be turned
on again after the cooling period
Burns on the cutting
surface
c) with longitudinal cuts
d) with cross cuts
a) Fastening nut tightened insufciently
b) Wrong saw blade
c) Longitudinal stop not parallel
d) Slide carriage not parallel
a) Insert a sharpened saw blade
b) Insert saw blade with 20 or 28 teeth for
longitudinal cuts
c) Exchange the longitudinal stop
Align the slide carriage with the saw blade
26 І 164

Scheppach HS100S Specifications

General

Blade bore	30 mm
Blade diameter	250 mm
Number of teeth	24
Idle speed (max)	5000 RPM
Cutting depth (90º)	-, 85 mm
Maximum cutting height	85 mm
Saw blade included	-
Height adjustment range	0 - 85 mm
Input power	2000 W
AC input voltage	220-240 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	940 mm
Width	780 mm
Height	1100 mm
Weight	19400 g
Bench depth	485 mm
Bench width	642 mm
