Art. no.: 2.511076 Rev.: g
Introduction 2
User Guide Menu Structure 2.6
BR-102 plus / BR-102 plus PWA
START
Measurement
starts and value
displayed.
OK
Measurement is displayed (or an error message is given).
Press OK again to return to the previous menu.
BREAK
Interrupt measurement: Press the break button when a measure-
ment is being taken to interrupt the measurement.
SYSTEM
SETTINGS Language ENG, DEU, FRA, ITA, SPA, POR, SWE, RUS.
DATE /
TIME
Date
Format
• DD.MM.YYYY
• MM/DD/YYYY
• yyyymmmdd
• ddmmmyyyy
• YYYY-MM-
DD
• YYYYMMDD
Set date
Set current date in the
format defined.
Time
Format
12, 24 hour Set time
Set current time in the
format defined.
SYSTEM
INFO
Serial number, Hardware and pneumatic index, software version, control (date that the
next test (MTK) is due), SD card capacity (if inserted)
SERVICE
AREA
Service informa-
tion and check
screens
Test
Calibra-
tion
In this menu option the BP measurement can be
checked against a calibrated manometer (
see Meas-
urement Check, page 55
).
Hardware
Setup
This is an information screen for Factory use only and
requires a password to enter.
LOG-
BOOK
This details the number of measurements made and the
number or errors registered.
BACK
Return to main
menu.
Main Menu
Sub
Menu 1
Value/Info
Sub Menu
2
Value/Info
Sub
Menu 3
Value/Info
