Schiller BR-102 PLUS - Cuff Preparation

Page 47
Art. no.: 2.511076 Rev.: g
Cleaning 5
User Guide Cleaning the Cuff and Pouch 5.2
BR-102 plus / BR-102 plus PWA
5.2.2 Cuff Preparation
Two types of cuff are available: Cuff type with a D-ring and cuff type
without a D-ring. Both are available in various sizes. The cuff
preparation procedure for cleaning is the same for both type and all
sizes.
Disconnecting the Pressure Hose and Removing the Microphone
and Bladder
Before cleaning, the microphone and the bladder must be removed
from the cuff and the pressure hose disconnected.
1. Disconnect the pressure hose from the cuff inflation bladder con-
nector by twisting the connector a quarter turn.
2. Gently remove the microphone from the microphone pouch by
pushing on the outside of the cuff to move the microphone along
the pouch channel until it can be removed from the cuff.
3. Remove the bladder from the cuff.
4. Fold the cuff and secure the cuff with the velcro strip.
5. Place the cuff in a cleaning bag and wash.
 Do not pull on the microphone lead when removing the
microphone as this can cause damage to the connections.
