Schiller BR-102 PLUS - Overpressure Relieve Valve

Page 57
Art. no.: 2.511076 Rev.: g
Maintenance 6
User Guide Measurement Check 6.4
BR-102 plus / BR-102 plus PWA
6.4.4 Overpressure Relieve Valve
The overpressure relieve valve can be checked for correct release for
both the adult settings and paediatric setting.
Adult
1. Set / check that Adult is set in the record setup. This can be done
for single measurement or new record:
2. Setup and enter the calibration screen as detailed on the previous
page.
3. Pump to 300 mmHg. Slowly continue to pump and check that the
overpressure valve activates (a pressure hiss is heard and the cuff
rapidly deflates) at 320 mmHg ± 10 mmHg.
Paediatric
1. Set the record setup to Child. This can be done for single meas-
urement or new record:
2. Setup and enter the calibration screen as detailed on the previous
page.
3. Pump to 200 mmHg. Slowly continue to pump and check that the
overpressure valve activates (a pressure hiss is heard and the cuff
rapidly deflates) at 225 mmHg ± 5 mmHg.
NEW RECORD
LAST RECORD
SINGLE MEAS.
SYSTEM
NEXT OK
05:16PM
RECORD SETUP
PROGRAM
PATIENT ID
START
BACK
NEXT OK
NEW RECORD
NEXT OK
RECORD SETUP
PatGrp ADULT
RecDur 24 hr
DefSpd 5 mmHg/s
DispResult ON
BACK
NEW RECORD
LAST RECORD
SINGLE MEAS.
SYSTEM
NEXT OK
05:16PM
RECORD SETUP
PROGRAM
PATIENT ID
START
BACK
NEXT OK
NEW RECORD
NEXT OK
RECORD SETUP
PatGrp CHILD
RecDur 24 hr
DefSpd 5 mmHg/s
DispResult ON
BACK
