Art. no.: 2.511076 Rev.: g
Maintenance 6
User Guide Error Messages 6.5
BR-102 plus / BR-102 plus PWA
182 Signal
disturbed
• Too much interference in Ko-
rotkoff signal.
 Perform measurement in quiet environment;
avoid moving the arm during measurement.
190 No signal • Pressure reached 50 mmHg
and no pulse detected (OSC).
 Check cuff.
191 Weak signal • Less than 8 pulse beats de-
tected (OSC).
 Check cuff.
192 Signal
disturbed
• More than 200 pulse beats
detected (OSC).
 Avoid moving the arm during measurement.
198 DIA not
detected
• Minimum pressure reached
without diastolic value detect-
ed (OSC).
 Avoid moving the arm during measurement.
199 SYS not
detected
• Minimum pressure reached
without systolic value detect-
ed (OSC).
 Avoid moving the arm during measurement.
200 No pulse • No pulse detected (OSC).
 Repeat measurement; check cuff.
201 Pulse > max. • Too many pulse beats detect-
ed (OSC).
 Perform measurement in quiet environment;
avoid moving the arm during measurement.
202 Pulse < min. • Too few pulse beats detected
(OSC).
 Repeat measurement; check cuff.
210 No pulse • No pulse detected (KOR).  Connect microphone; Check position of
microphone. Ensure that the microphone is
correctly orientated (metallic (yellow) side
towards arm).
211 Pulse > max. • Too many pulse beats detect-
ed (KOR).
 Perform measurement in quiet environment;
avoid moving the arm during measurement.
212 Pulse < min. • Too few pulse beats detected
(KOR).
 Place microphone over brachial artery;
ensure that the microphone is correctly
orientated (metallic (yellow) side towards
arm).
238 Min. pressure • Minimum pressure reached
without measurement result.
 Repeat measurement.
239 Max. pressure • Maximum pressure reached
without measurement result.
 Repeat measurement.
255 Internal error • Device is defective.
 Contact technical service.
322 No
measurements
available
• No recording stored.
• No recording has been made.
• Incorrect initialisation of a re-
cording.
• Error in the recording storage.
 Take/ retake a recording.
323 No patient data
available
• No patient data has been re-
corded.
 Enter patient data.
324 SD- card
missing
• SD card not inserted. For
PWA recording an SD card is
necessary.
 Insert an SD card.
No. Message Cause Remedy
