Schlage GF3000 - Standard and TRD Door Prep (continued); Hollow Metal;Aluminum - 1-3;4 to 2-1;2 Depth; Wood Door Prep; TRD Door Prep

GF3000 SERIES INSTALLATION MANUAL
Installing a GF3000 Series Lock
Standard and TRD Door Prep (continued):
DOOR PREP
• Hollow Metal or
Aluminum
• Depth: 1-3/4” to 2-1/2”
DOOR PREP
• Wood
DOOR PREP - TRD
• Hollow Metal or
Aluminum door where
the top adjustment is
not accessible.
• Depth: 1-3/4”
Page 11
MINIMUM 1-7/8”
DOOR THICKNESS
