GF3000 SERIES INSTALLATION MANUAL
Confirming the Box Contents
Confirming the Box Conte nts
Confirming the Box Contents
Page 3
k
b
a
c
- MAGNETIC COIL ASSEMBLY
- ARMATURE
- ARMATURE MOUNTING ASSEMBLY
- MOUNTING TABS
- HEX WRENCH
- SHIM PLATE
- HARDWARE PACK
- MAGNETIC COIL HOUSING
- ARMATURE HOUSING
- FACE PLATES
- THRESHOLD BOX
a
b
c
d
e
f
g
h
i
j
k
