Heating Schedule 2/3
9. Tap the “Left Arrow” button on the “Your Week Type” screen to exit.
10. Tap the “Event Schedule” button to set up the target/setpoint temperature and
start time for each event.
11. Tap the temperature if you want to change it, then tap the “Up Arrow” or “Down
Arrow” button to set the required temperature.
12. Tap the time if you want to change it, then tap the “Up Arrow” or “Down Arrow”
button to set the time in steps of 15 minutes. Confirm with “√”.
13. Tap the “Left Arrow” or “Right Arrow” button to toggle through the various
events.
14. Once you have completed setting all the events, tap the “Right Arrow” button
to view a confirmation screen and return to the Heating Schedule menu.
The thermostat is preset to operate in Scheduled Operation with four events per
work day and two events per home day.
This can be changed to six events per work day and two events per home day in
the following way:
15. In the “Heating Schedule” menu, tap the ”Events per Day” button.
16. On the explanation screen, tap the “Right Arrow” button.
17. Choose between four and six events per work day. Confirm with “√”.
Steps 10 to 14 may need to be repeated to set the new events.
Your Week Type:
Work days/home days
All days are different
9
Your Week Type:
Work days/home days
All days are different
9
Week Type
Event Schedule
Events per Day
10
Work Day: Wake Up
24.5° 08:00
11
Work Day: Leave Home
24.5° 09:00
13
12
13
Done
14
Week Type
Event Schedule
Events per Day
15
You can set the thermo-
stat for a maximum of 4
or 6 events per day
16
4 Events per Day
6 Events per Day
17
>
<
