Temperature Scale 2/3
• Minimum Temp. Limit – use this setting to maintain a comfort temperature on tile
floors. Can be set between 5°C and 25°C.
• Maximum Temp. Limit – use this setting to protect wooden floors from excessive
temperatures. Can be set between 10°C and 40°C.
NOTE: If the maximum limit for floor temperature is set too high, sensitive floor types
may be permanently damaged.
1. Tap the “Menu” button on the home screen.
2. Then tap the “Engineer Settings” button.
3. Scroll down and tap the “Temp. Scale” button.
4. Confirm that you want to set minimum and maximum operating temperatures for
the thermostat by tapping “√” or cancel with “X”.
5. If “√” is chosen, you can set a Minimum Temp.Scale.
6. Use the “Up Arrow” or “Down Arrow” button to change the Minimum Temp.
Scale.
7. Confirm the setting with “√”.
8. You can now set a Maximum Temp.Scale.
9. Use the “Up Arrow” or “Down Arrow” button to change the Maximum Temp.
Scale.
10. Confirm the setting with “√”.
If “Room/Floor Limit” has been selected under “Sensor Application”, proceed
to step 11. Otherwise, proceed to step 16.
Mon 11:15
17:00
23.5
°
Manual Other...
1
Mon 11:15
17:00
23.5
°
Manual Other...
1
Set the min and max
temperature that the
thermostat can operate
at
4
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
Minimum Temp. Scale
15°
5
6 67
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Maximum Temp. Scale
35°
8
9 910
Temperature scale and
Limit calibrated
8
