Room Sensor Calibration
This option allows you to calibrate the room sensor.
You should calibrate the sensor if the temperature reading diers from the actual
room temperature.
You can calibrate the sensor with +/- 10°C in steps of 0.5°C in the following way:
1. Tap the “Menu” button on the home screen.
2. Then tap the “Engineer Settings” button.
3. Scroll down and tap the “Room Sensor Calibration” button.
4. Confirm that you want to calibrate the sensor with “√” or cancel with “X”.
5. If “√” is chosen, you must then oset the thermostat to reflect the room
temperature actually measured.
6. Use the “Up Arrow” or “Down Arrow” button to set the measured room
temperature.
7. Confirm the value with “√”. A confirmation screen will be displayed briefly.
8. The thermostat will automatically return to “Engineer Settings”.
Room sensor calibrated
Mon 11:15
17:00
23.5
°
Manual Other...
1
Mon 11:15
17:00
23.5
°
Manual Other...
1
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
2
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
3
Current reading from
room sensor is
23.2°
Calibrate sensor?
4
Actual Room Temp.
24.3°
6 7 6
>
<
