Sensor Type
This option allows you to choose the type of floor sensor used with the thermostat.
You can therefore choose to use an existing sensor with the thermostat, e.g. in
renovation projects.
Choose the sensor actually used from the list. The sensor supplied with the thermostat
is an OJ sensor listed as: “Factory”.
• Factory (default)
• Sensor 6,8 kΩ
• Sensor 10 kΩ
• Sensor 12 kΩ
• Sensor 33 kΩ
• Sensor 47 kΩ
• Custom
1. Tap the “Menu” button on the home screen.
2. Then tap the “Engineer Settings” button.
3. Scroll down and tap the “Sensor Type” button.
4. Tap the type of floor sensor actually used.
5. Confirm your choice with “√” or discard it with “X”.
6. If “Custom” is chosen, you must provide resistance values for the sensor
concerned at four given temperatures: 15°C, 20°C, 25°C and 30°C – ask the
supplier of your sensor for these values.
7. Use the “Right Arrow” or “Left Arrow” button to toggle through the
temperatures.
8. Tap the resistance value to change it.
9. Tap the “Up Arrow” or “Down Arrow” button to set the resistance.
10. Then repeat steps 6-9 until all four resistance values have been set.
11. Tap the “Left Arrow” button to return to “Engineer Settings”.
You have now set up
your custom sensor
Mon 11:15
17:00
23.5
°
Manual Other...
1
Mon 11:15
17:00
23.5
°
Manual Other...
1
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
Heating Schedule
Energy Use
User Settings
Engineer Settings
2
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
Sensor Application
Adaptive Function
Open Window
Factory Reset
Temp. Scale
Room Sens. Calibr.
Floor Sens. Calibr.
Sensor Type
3
Sensor - 10 kΩ
Sensor - 12 kΩ
Factory
User Settings
Sensor - 10 kΩ
Sensor - 12 kΩ
Factory
User Settings
Sensor - 10 kΩ
Sensor - 12 kΩ
Factory
User Settings
4
Thermostat will use a
custom sensor type. Set
the 4 resistance values
for it ?
5
Custom Sensor
Value 1
2303
Ω
15°
6
8
7
7
Custom Sensor
Value 2
2303
Ω
20°
8
7
7
Custom Sensor
Value 3
2303
Ω
25°
8
7
7
Custom Sensor
Value 4
2303
Ω
30°
8
7
11
>
<
