Technical data
18 02.00 | JGP-P | Assembly and Operating Manual | en | 1469637
3 Technical data
Connection data
Designation JGP-P
Pressure medium Compressed air,
compressed air quality
according to
ISO 8573-1: 7:4:4
Nominal operating pressure [bar] 6
Minimum pressure [bar]
without maintenance of gripping force
with maintenance of gripping force
2.5
4
Maximum pressure [bar]
without maintenance of gripping force
with maintenance of gripping force
8
6.5
Pressure range for air purge [bar] 0.5 – 1
Ambient conditions and operating conditions
Designation JGP-P
Ambient temperature [°C]
min.
max.
+5
+90
Protection class IP 40
Noise emission [dB(A)] ≤70
More technical data is included in the catalog data sheet.
Whichever is the latest version.
