Assembly and settings
34 02.00 | JGP-P | Assembly and Operating Manual | en | 1469637
5. Turn adjustable spindle (5) in order to adjust the position of
the control cam (6).
✓ Part gripped (O.D. gripping):
Slide control cam (6) outwards until the sensor (1) no longer
responds.
✓ Move the control cam (6) back towards the inside until the
sensor (1) begins to switch.
✓ Part gripped (I.D. gripping):
Slide control cam (6) inwards until the sensor (1) no longer
responds.
✓ Move the control cam (6) back towards the outside until the
sensor (1) begins to switch.
6. Screw the expander bolt (4) back in to fix the switching point.
For tightening torque see following table
7. Open the product and close it again in order to test its
function.
Item Mounting JGP-P
64 80 100 125 160 200 240 300
4 Max. tightening torque
[Nm]
0.2 0.2 0.3 0.3 0.4 0.4 0.4 0.4
5 Max. adjusting torque
[Nm]
0.2 0.2 0.3 0.3 0.4 0.4 0.4 0.4
