Assembly and settings
40 02.00 | JGP-P | Assembly and Operating Manual | en | 1469637
3. Adjust sensor (1), see sensor assembly and operating manual.
Size l1* [mm] Size l1* [mm]
40 11.9 100 27
40 AS 11.9 100 AS 27
40 IS 21.9 100 IS 53
50 22 125 30
50 AS 22 125 AS 30
50 IS 38 125 IS 60
64 17.8 160 38
64 AS 17.8 160 AS 33.5
64 IS 35.8 160 IS 78.5
80 25.8 200 32
80 AS 25.8 200 AS 32
80 IS 43.8 200 IS 90
