16 14.00 | SRU | Assembly and Operating Manual | en | 389439
3 Technical data
3.1 Type key
SRU mini-8 - W- M - 4 - EX-
Size
8 12 10 14
Dampening method
S = speed W = soft H = hard
Center position
– = no M = pneumatic
Fluid feed-through
– = no 2 = 2 channels 4 = 2 channels
Explosion-protected version
– = no EX
3.2 Basic data
Operating data
Designation SRU 8, 10, 12, 14
S/H/W
Angle of rotation [°] 180
End position adjustability [°]
Min.
Max.
-3
+90
Repeatability [mm] < 0.07
Pressure medium Compressed air, compressed air
quality according to ISO 8573‐
1:2010 [7:4:4]
Nominal operating pressure [bar] 6
Min. pressure [bar] 4.5
Max. pressure [bar] 8
More technical data is included in the catalog data sheet.
Whichever is the latest version.
