Design and description
18 14.00 | SRU | Assembly and Operating Manual | en | 389439
4 Design and description
4.1 Design
Pneumatic Rotary Unit, variant "S" displayed
1 Pinion
2 Main air connections
3 Housing with grooves for sensors
4 Shock absorbers
5 Sleeve for adjusting the end positions
4.2 Description
The product is a pneumatic miniature swivel unit for rotating and
swiveling movements with various options.
l
Hydraulic dampening (variant H)
l
Elastomer dampening (variant S)
l
Without dampening (variant W)
l
Pneumatic center position (variant M)
l
Fluid feed-through
