Assembly
20 14.00 | SRU | Assembly and Operating Manual | en | 389439
NOTE
l
Observe the requirements for the compressed air
supply, }3 [/16].
l
In case of compressed air loss (cutting off the energy line),
the product loses its dynamic effects and does not remain in
a secure position. However, the use of a SDV-P pressure
maintenance valve is recommended in this case in order to
maintain the dynamic effect for some time.
1. Screw the product to the machine/system, }5.2.1 [/20].
ð Use centering sleeves.
ð Observe the tightening torque for the mounting screws,
see the following table.
2. Fasten attachment with two cylindrical pins and two
fastening screws to the pinion, }5.2.1 [/20].
IMPORTANT!Insert the cylindrical pins by hand. Do not
hammer the pinion.
3. In the main air connections "A" and "B", screw in throttle
valves and connect compressed air lines, }5.2.2 [/22].
OR with hose-free direct connection:
ð Mount throttle valves in the supply lines "a" and "b".
ð Use O-rings from the accessory pack.
4. Check that all of the throttle valves are closed.
5. Screw in locking screws in open and not required air
connections where appropriate.
6. Adjust end positions, }5.3.1 [/23].
7. Adjust center position if necessary, }5.3.2 [/24]
8. Mount sensor if necessary, }5.4 [/25].
9. Adjust swiveling speed, }6.1 [/28].
10. Adjust shock absorber stroke, }6.2 [/30].
5.2 Connections
5.2.1 Mechanical connection
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
Tab.: Requirements for evenness of the mounting surface (Dimensions in mm)
