Specifications
Operation Manual -
SP 305
12
4/30/12
SPECIFICATIONS
Note! All specifications are subject to change without notice.
** Max RPM of the hydraulic pumps is calculated while the pump is under a full load. Depending on the unit it is acceptable for
the max RPM to vary slightly from the published estimate.
Model
SP 305
Pump Kit
2.5/1.75 x 30:5
Orientation
Piston Side
Strokes/minute (max.)
40
Material Output (max.)
30 yd
3
/hr (23 m
3
/hr)
Material Pressure (max.)
625 PSI (43 bar)
Power (Diesel Engine)
CAT C2.2NA (Tier 4 interim)
50 HP (37 Kw)
Power (Electric Motor)
40 HP (30 Kw)
Power (hyd. pumps)
30 Kw
Output (hyd. pumps)
27 GPM (102 lpm)
Speed (hyd. pumps) (diesel)
2700 RPM**
(elect. motor)
1800 RPM
Pressure (max. hyd.)
2500 PSI (172 bar)
Max. horizontal distance
800 feet (244 m)
Max. vertical distance
200 feet (61 m)
Max. aggregate size
1” (25 mm)
Minimum Slump
0”
Material Cylinder Diameter
5” (125 mm)
Stoke Length
30” (762 mm)
Differential Cyl. Diameter
2.5 (63.5 mm)
Concrete Valve Type
S
Hopper Height
42” (1065 mm)
Fuel Tank Capacity
15 gal. (58 l)
Gross Weight
3400 lb. (1525 Kg)
Length
149” (3785 mm)
Width
64” (1625 mm)
Height
66” (1675 mm)
Remote Cable Length
100 ft. (30.5 m)
Electric Motor (optional)*
*Contact Schwing America for specs
*
