SciQuip Incu-Shake Compact User Manual

INCU-SHAKE Compact Stackable shaking Incubator Manual V2023.1
10
4.2.8 Specifications
Machine
Shaking Unit
Outside (WxDxH)
840x764x625mm
Drive Type
Direct Beltless Driving System
Inside (WxDxH)
570*505*418mm
Tray Size (WxD)
500x400mm
Volume
120L
Maximum Load
15kg
Net / Gross Weight
120kg/165kg
Speed Range
30-300 rpm
Control Panel
TFT Touch Screen
Speed Accuracy
±1 rpm
Illumination
LED
Timer
0-9999 mins
Language
English
Shaking Mode
Orbital
Ambient TEMP.
5-35°C
Shaking Diameter
1-50mm Stepless Adjustment
UV Light
254nm, 11W
Temperature
Noise Level
<55 dB (1m above floor)
Control Mode
Fixed Value & Program
Power
765W
TEMP. Range
Ambient-15 to 60°C (Min. 4°C)#
Electricity
AC 220-240 Volt, 50/60Hz
TEMP Accuracy
0.1°C
Data logging
USB port
TEMP. Uniformity
±0.5°C @37°C
Static Shelf
Standard, 1 piece
Principle of Sensor
PT100
Base Stand
Standard: H 15cm
Options: H 35cm or H 50cm
Air Circulation
360m3/Hour
Key Lock
Yes, standard
Recovery (@37°C)
8 mins (30 Seconds Door Opening)
Photosynthetic Lighting
Part NO.
P5031RB
P5031WW
Light Type
LED, 50% Red, 50% Blue
LED, 100% Warm White
Spectrum
Red: 640-660nm, Blue: 430-450nm
4000k:400-700nm
Light Intensity
Up to 350 μmol/(m2*s)
Up to 220 μmol/(m2*s)
Control
Yes, Individually, from 0-100% output
Yes, from 0-100% output
Power
120W
60W
Control Mode
Fixed Value & Programmable
Dimensions (WxDxH)
550x430x10mm
# Min. 15°C when Photosynthetic Lighting option is applied.
