⚫ After the first data record is saved, the system will create a folder ( NO"XXX")
in the root folder. "XXX" is based on the "Address" set in "COM" menu. For
example, if the unit address is set as "1" the folder name will be "NO001".
⚫ All data are saved and exported as csv. format in the folder "NOxxx".
⚫ The operating data is recorded once a minute. The system can export a
maximum of 6 days of data. Once the maximum limit is reached, the earlier
data will be overwritten by the new data.
6.11 Using Illumination & UV Light
To switch on the Illumination light, press the illumination light switch on the front panel.
The incubator is equipped with a UV light behind the back panel of the inner chamber.
The air is sterilized when passing through the back plenum. As it is not exposed to the
inner chamber, so it is safe to switch on the during the operation.
To switch on the UV light, press the UV light switch next to the illumination light switch.
6.12 Using Sticky Mat
The Sticky Mat is used for attaching vessels, such as flaks, bottles, dishes etc onto
the shaking platforms for all shaking equipments, for example, shakers, rockers as
well as shaking incubators. It is as standard 20 x 20 cm in size and can be used to
cover the shaking platforms replacing the traditional flask clamps. The Sticky Mat
can be easily removed and repositioned by simply peeling off the shaking tray
surface. With proper care, the Sticky Mat can be used for several years.
6.12.1 Loading/Unloading the Sticky Mat
Load vessels onto the surface of the Sticky Mat by pressing them firmly into
designated place. Tilt each vessel gently to check that they are adhering firmly.
To unload the vessels, tilt the neck of the vessel gently to one side. Wait until the
vessel has detached from the Sticky Mat. Large vessels may take about 20-30
seconds to be detached.
ATTENTIONS：
1. The Sticky Mat is only used for undamaged,
unscratched cultivation vessels with large, clean, dry
and flat bottom.
2. Make sure the Sticky Mat is undamaged, clean, dry
and oil free.
ATTENTIONS：
For unloading vessels with large bottom, squirt a few
drops of water along the edge of the vessel. Tilt the neck of
the vessel gently to one side.
