INCU-SHAKE Compact Stackable shaking Incubator Manual V2023.1
13
5.8 Installation of Sticky Mat (Applies P6041 plain tray)
The tray is specially designed for use with SciQuip Sticky Mats. The Sticky Mat is used for
attaching vessels, such as flasks, bottles, dishes etc onto the shaking platforms for all shaking
equipment, for example, shakers, rockers as well as shaking incubators. It is as standard 20
x 20 cm in size and 4 pcs as maximum, can be used to cover the shaking platforms replacing
the traditional flask clamps. The Sticky Mats can be easily removed and repositioned by
simply peeling off the shaking tray surface. With proper care, the Sticky Mat can be used for
several years.
⚫ Before installing the Sticky Mat, clean the surface of the platform tray, making sure the
platform is completely undamaged, clean and oil-free.
⚫ Moisturize the platform tray by spray bottle or wet towel.
⚫ Remove one of the two plastic sheet covers of the Sticky Mat. Dip the sticky mat with
water.
⚫ Install the Sticky Mat onto the platform tray. Use the ruler or hard card to scrape and
squeeze out all the water and bubbles.
⚫ Wait for 12 hours and peel off the top sheet cover.
⚫ The Sticky Mat is now ready for loading.
⚫ Maximum loading capacity with P6041 plain tray with Sticky Mats
For Erlenmeyer Flasks only. Flask dimensions may reduce max. capacity
5.9 Operation of Shaking Diameter Adjustment
The incubator has an adjustable shaking diameter of Ø1-50mm. To adjust it, follow the
instructions below,
5.9.1 Tools needed: 17*19 spanner, 8*10 spanner, Allen key 6mm, Allen key 8mm
5.9.2 Turn off the unit, open the glass door, pull out and remove the shaking tray,
5.9.3 Use the 8mm Allen key to loosen the (A) central Allen screw.
To Next Page
