SDMO R44C3 - Page 14

Control
Figure 2.1.3 : General description of the generating set
Note : Photo presented with the Nexys control unit.
1 Control unit 4 Working hours counter
2 Emergency stop 5 Power circuit breaker
3 Socket control panel 6 Connection terminal block
6
5
2
3
1
4
