6.2.2 Manual starting
Check that the generating set circuit breaker has triggered.
Danger
î™® connect the generating set battery.
 turn the key switch to the ON position (without forcing it)
 All of the LEDs light up for 2 seconds, to confirm that they are operating correctly.
 If the LEDs do not light up, check the protection fuse and replace it if necessary.
 All the items on the screen are displayed for 2 seconds.
 Only the "ON" LED remains lit to indicate that the module is powered up.
 The following screen appears.
The first line displays the motor speed in RPM.
The second line displays the battery voltage in
volts (V).
 Check the battery voltage (min. 12 V)
î™° Press (once briefly) the green "START" button.
 If the motor is equipped with an air preheating system, there is a 10-second delay before the motor starts (preheating
activation period).
 The following screen appears
The third line displays the air preheating time
remaining (with pictograms representing a
resistor and an hourglass).
 If the motor is not fitted with an air preheating system or once the preheating delay has elapsed, the engine starts up
(start of a cycle comprising 3 attempts to start up the engine).
 The following screen appears.
The number of successive and automatic starting attempts is limited to 3.
Warning
Note: the LED
flashes as soon as the START button is pressed and continues to flash until the frequency stabilises if
a "measurements" card has not been inserted and until the frequency and voltage stabilise if a "measurements" card has been
inserted.
Following stabilisation, the LED light comes on
continuously.
