6.3.2 Starting
Check that the generating set circuit breaker has triggered.
Danger
î™® Connect the generating set battery
 Turn the key switch to the ON position (without forcing it to the ON position), the ON lamp will light up (if the lamp does not
light up, check and replace the fuse if necessary)
 Test the Alarm and Fault LEDs (menu 15 – TEST LAMPS)
1 ACTIONS
1/5
11 MANUAL <> AUTO
12 CONTROL LOAD
13 TEST GENERATING SET
14 PROGRAMS
15 TEST LAMPS
12 OK Esc
î™± Press "Esc" several times to return to the following home menu
OPERATION
MANUAL
Press START
to start
24/08/2005 13:12
Check the battery voltage
 Press START:
AIR PREHEATING
10 seconds
24/08/2005 13:12
 If the engine is equipped with an
air preheating system, there is a
delay (adjustable) before the
engine starts (preheating
activation period).
 If the motor is not fitted with an
air preheating system or once the
preheating delay has elapsed,
the engine starts up (start of a
cycle comprising 3 attempts to
start up the engine).
START-UP
IN PROGRESS
24/08/2005 13:12
Warning: the number of successive
and automatic starting attempts is
limited to 3.
The following pictogram will flash
AVAILABLE POWER
100.0%
24/08/2005 13:12
The following pictogram is displayed
The following information is displayed
Speed of rotation
Coolant temperature
Options
Oil pressure
Oil Temperature
