SDMO R44C3 User Manual

2.1. Technical specifications
Range / Generating set type RENTAL POWER / R44C3
Weights and Dimensions
Dimensions with high autonomy tank
Dimensions l x w x h
2200 mm x 1000 mm x 1528 mm
Weight:
1150 kg dry weight / 1350 kg in operating configuration
Hood:
M3127
Sound pressure level:
at 1 m: 73 dB(A)
measurement uncertainty : 0.70
Output
Voltage Hz Phase Load factor
Max current (A)
Emergency
power
1
kW / kVA
Prime power
2
kW / kVA
400/230 50 3 0.8 58 32 / 40 29 / 36
(1) ESP: Stand-by output available for emergency use under variable charge up to 200hrs per year as per lSO 8528-1, no overload availabl
e
under these service conditions.
(2) PRP: Main output available continuously under variable load for an unlimited time period per year as per ISO 8528-1, an overload of 10
%
one hour every 12 hours is available, as per ISO 3046-1.
- Term of use :
Standard reference conditions ESP/PRP 40° / 40°, Air Intlet Temp, 1000m / 1000m mA.S.L. 60 % relative humidity.
Engine data
Manufacturer / model MITSUBISHI S4S-Z3DT61SD
Type 4 Cycles Naturally aspirated
Cylinder configuration 4 XL
Cubic capacity 3.33 L
Rotation speed 1500 Rpm
prime power at nominal speed 36 kW
Adjustment type Mechanical
Fuel consumption
100 % main power 10.4 L/h
Fuel
Fuel type Diesel
High autonomy fuel tank 220 L
Lubrication
Oil capacity 10 L
Min. Oil pressure 1 bar
Nominal oil pressure 3.9 bar
Oil consumption (100 % load) 0.11 L/h
Oil sump capacity 9 L
Type of lubricant Genlub
Cooling
Engine capacity with radiator 9.5 L
Max coolant temperature 102 °C
Fan power 0.8 kW
Refrigerant type Gencool
Thermostat 76.5 – 90 °C
13/202
