46
24) Rear Storage
Compartment
REAR STORAGE COMPARTMENT
1. Engine cover opened
The rear storage compartment is con-
venient for carrying large personal arti-
cles. It is an ideal location for spare
Personal Flotation Device (PFD), tow-
els, lunch etc.
Pull latch to open engine cover.
The gas assist cylinders will ease
opening and hold engine cover open.
25) Bimini Top
The Bimini top is convenient for protec-
tion against inclement weather or sun-
shine.
Opening Bimini Top
Lift sun pad lid.
Slightly raise Bimini top above engine
storage compartment and slide all the
way to front of side rails.
1. Bimini pivot base pulled forward on rail
Unzip cover and remove. Store cover in
a storage area.
Lift Bimini top to vertical position and
connect front straps to eyelets on body
of boat.
1. Hook strap to body eyelet
Pull canvas back and fasten rear straps
to eyelets on body of boat.
Adjust strap tension as needed.
Close sun pad lid.
WARNING
Never leave any heavy or break-
able objects in the storage com-
partment. Never operate the boat
with the engine cover open.
WARNING
• Do not use Bimini top as a support.
• Operate boat only at low speeds
if Bimini top is in use.
• Top can break or dislodge caus-
ing a risk of personal injury or in-
terference with boat operation.
1
F10L3BY
1
F21L02Y
1
F21L03Y
lmo2005-006a_1.book Page 46 Wednesday, July 7, 2004 1:06 PM
