Access to the main fuses is by remov-
ing the battery cut-off switch from the
gunwale. Remove the 4 screws from
the mounting ring and pull switch as-
sembly into storage area.
1. Remove these screws
TYPICAL
1. Automatic bilge pump fuse
2. Main fuses
Installation is reverse of removal.
Engine
Refer to M
2
Jet Drive Operator‘s Guide.
Bilge Air Blower
Verify bilge air blower operation. It is
located inside engine compartment
beneath ventilation duct.
Clean both openings. Ensure that both
openings are not obstructed. See next
illustration.
1. Bilge ventilation ducts
Navigation Light Bulb
Replacement
Bow Light
TYPICAL
1. Gently pry here with a screwdriver
F10H0PY
1
F10H0QY
1
2

WARNING
If bilge blower does not operate
refer to an authorized SEA-DOO
sport boat dealer before starting
the boat.
F10L2N1
1
F04H2QY
1
