COCKPIT TABLE INSTALLED
Close sun pad lid.
Cockpit Table Storage
Storage of cockpit table is the reverse
of installation.
29) Jet Pump Water Intake
The water is drawn up by the impeller
through this opening. The grate mini-
mizes entry of foreign objects into the
propulsion system.
Refer to M
2
Jet Drive Operator‘s Guide
for more detailed information.
30) Bow and Stern Eyelets
Bow Eyelet
Eyelets can be used for mooring, tow-
ing and as a tie-down point during trans-
portation.
TYPICAL
1. Bow eyelet
Stern Eyelets
This eyelet allows a rope with a hook,
a closes end or an open end to be at-
tached.
TYPICAL
1. Stern eyelets
WARNING
Cockpit table must be properly
stored before operating boat.
WARNING
Keep away from intake grate while
engine is on. Items such as long
hair, loose clothing or personal flo-
tation device straps can become
entangled in moving parts result-
ing in severe injury or drowning.
F21L0DY
F09L3YY
1
F10L39Y
1
