87
ELECTRICAL (cont’d)
Fuse
Gauges/low oil 3 A
Courtsey lights 1 A
Horn 10 A
Bilge blower 5 A
Bilge pump 3 A
Navigation/Anc
lights
3 A
12-Volt outlet 10 A (2)
Radio 5 A
Main battery fuses 20 A (3)
Automatic bilge
pump
7.5 A
ADDITIONAL INFORMATION:
➀ Recommended: See Mercury Marine recommendations.
Battery posts: On top. Round taper type.
Battery maximum allowed size: 267 mm (10-1/2 in) long x 172 mm (6-3/4 in) wide x 238 mm
(9-3/8 in) high.
CARBURETION
Refer to M
2
Jet Drive specifications for more detailed information.
COOLING
Type Open circuit — Direct water flow
PROPULSION
Propulsion system Mercury Marine Sport Jet
Number of pumps 1
Jet pump type Mixed flow, single stage
Steering nozzle pivoting angle 26°
Minimum required water level 90 cm (36 in)
Refer to M
2
Jet Drive specifications for more detailed information.
DIMENSION
Dead rise 20°
Draft 30.5 cm (12 in)
Overall length 5.56 m (18 ft 3 in) 5.91 m (19 ft 5 in)
Overall width (beam) 2.44 m (8 ft)
Dry weight
930 kg (2050 lb)
with 200 Optimax
957 kg (2110 lb)
with 240 EFI
1056 kg (2330 lb)
with 240 EFI/
250 Optimax
Load limit (passengers + luggage)
8 passengers or 600 kg (1320 lb)
(based on calm water operation)
MODELS UTOPIA 185
UTOPIA 205/
205 SE
lmo2005-006a_5_maintenance.fm Page 87 Wednesday, July 7, 2004 1:14 PM
