Every time an adjustment is made reset the board turning OFF the power for 10 seconds and then turn it back
ON.
The gate opens but
Advises
Problem Found Possibile Cause Solutions
Make sure all Safety LED are turned ON
All not-used N.C. contacts must have jumpers
Motor doesn't respond
a)
to any START command
Jumper missing on one of the
N.C. Contacts
b) Receiver doesn’t work (LED 3
in not turned ON)
c) Burnt fuse
d)
The Auxiliary contact is set as
a N. C. Conntact
a) Check Connections or Jumpers
on Contacts 9/11 - 10/11 on the Cn2
and 2/6 on Cn1
b) Check connection, polarity and
fuse of the receiver
c) Replace burnt fuse on the
Board
d) Set the Auxiliary contact as a
N.O. setting Dip Switches
3 in ON position
Gate doesn't move while
the motor is running
a)
The Motor is in the Released
position
b)
The electronic / mechanic Clutch
or By-pass Valve are not set
c)
There is an obstacle or the motor
has reached a limit switch
a) Re-lock the motor
b) Adjust Electronic clutch using
Trimmer Rv1 or Motor Clutch / By-
pass Valve
c) Remove obstacle or switch the
the operating direction using
Dip Switch 12
Gate doesn't reach the
complete Open / Closed
a)
position
Wrong setting of the Limit
Switches
b) Erron on Programming
(page 10)
c) Gate is stopped by an
obstacle
d)
The fitting Geometry is inadequate
a) Set Limit Switches
b) Repeat Programming as on
page 10
c) Remove obstacle
d) Check fitting geometry following
the operator installation manual
doesn't close
a)
The photocell Contacts
9/11 and 10/11 are not closed
b)
The auxiliary contac
is set as a N.C.
a) Check LED or jumpers
b) Set the Auxiliary contact as a
N.O. setting Dip Switch 3 in ON
The gate doesn't close
automatically
a)
The Automatic Closing is OFF
b) Pause time set to High
a) Activate Automatic Closing by
Dip Switch 6
b) Adjust Pause time using Trimmer
Rv3
GATE 2
TROUBLESHOOTING
23
International registered trademark n. 2.777.971
REV 05 - 10/2010
