MMX
TM
User Guide
19
CO Maint
This report specifies which CO device (if used) needs to be replaced.
Step 3: Select Node and Loop number
• Select a Node and Loop number by using and
to scroll through the numbers.
• Select the Node by pressing .
• Select the loop number by pressing . Use
and to scroll the cursor through the
Obscuration, if viewing on the screen.
• Press to exit to the Reports Menu.
An example of the information displayed on screen:
The first and second line pinpoint the exact device.
Below that is the present obscuration percentage of
the device.
Step 1: Select CO Maint
1. Use and to scroll the cursor to “CO
Maint”.
2. Press to select the CO Maint submenu.
Step 2: Print or View CO Maint
• To print the Obscuration report to the printer, press
when the cursor flashes beside “Printer”.
Go to Step 3.
• To view the CO Maint log on the screen, press
then to select “Screen”. Go to Step 3.
-Select Node & Loop -
Node: A
L L
Node 33 Lp2 Addr 1
P h o t o De t e c tor
C u r r e n t O b s c : 0 . 0 0 %
^
- Reports Menu -
6 Current PWs
7 Obscurtion
8 CO Maint
9 Battery Voltage
- Report to -
1 Printer
2 Screen
To Next Page
